Nitro Sport

NITRO SPORT

Nitro Sport™ exemplifies Stanbee’s quest for thinner, stronger, more resilient components. As part of our proprietary foaming process, we inject nitrogen gas into its polymer core—resulting in exceptionally lightweight heel counters and box toes. Plus, it retains its shape and offers unrivaled flexibility. Nitro Sport™ contains 66% recycled material and is available in our Zero Waste Net Part Program. It’s a sustainable, high-quality, cost-effective solution for all of your heel counter or box-toe applications. Our standard offerings are below. Call about custom options with and without laminates.

[ CLICK HERE FOR PRINTABLE PRODUCT DATA SHEET ]

SPECIFICATIONS

GRADE & GAUGE (±5%)

Nitro Sport™	0.4 mm
Nitro Sport™	0.6 mm
Nitro Sport™	0.8 mm
Nitro Sport™	1.0mm

WORK PREPARATION

Cutting:

Cut in any direction to maximize yields.

Heat activation:

Bond-line temperature 80°C to 90°C. Recommended 85°C.

COOLING:

Cool product to ensure bond-line temperature of roughly 30°C before de-lasting.

GENERAL INFORMATION

SHEET SIZE:

101.6cm x 152.4cm (40" x 60")

AREA:

1.85SY – 1.55SM

PACKAGING:

500 SHEETS PER PALLET

STORAGE:

Store in a dry area. Recommended shelf life 2 years.

COMPOSITION

Nitro SPORT™ components are made from a proprietary blend of resins. Both outer layers have an exclusive hot-melt adhesive that bonds to all uppers, even leathers with a high oil content.

ZERO WASTE PROGRAM

This product is part of our Stanbee Zero Waste Program. It is ordered by the part instead of by the sheet, and all cutting waste is recycled in house. Provide a DXF file of the full-size run, and we’ll deliver production-ready components.
